FA-SA
VACUUM STEAM GENERATORS
Code: 8.451.0202
IVP 4.1 VAC
Features
Stainless steel body AISI 304. steam Ready warning lamp. Water heater 3kW s/s AISI 304-Thickness 25/10. Low level water indicator lamp. Boiler is refilled continuously. Switch for using chemicals and detergents mixed with steam. Device for cleaning hot water mixed with steam. Washable. filter Flex hose 4 m. Recovery tank capacity 64 l. Drain hose system. Steam regulation. Wheels suitable for use in food processing. Blower system area available. ON/OFF main switch with indicator lamp. ON/OFF boiler switch with indicator lamp
Technical characteristics
| Max steam pressure | 7 bar |
| Temperature | 158 °C |
| Boiler power abs | 3000 W/230 V-50 Hz |
| Steam production | 3,5 Kg/h |
| Water tank/détergent tank capacity | 5/5 l. |
| Absorbed power vacuum motor | 1100 W |
Standard accessories
230 mm squeegee Frame
150 mm squeegee Frame
Rectangular nozzle small brush
rectangular nozzle small Brush
small rectangular Nozzle steam/vacuum-
frame for 300 mm
liquid Frame 300 mm
support Accessory steam/vacuum brush-
Launches flat?? 35
Connecting accessories with steam/vacuum nozzle-
& nbsp; small Brush??? 30 nylon
small Brush d. 30
brass
Small brush d. 30 stainless steel
& nbsp; small Brush d. 30
steam/vacuum Extension-
suction hose
