Fasa A35 8500

Floor scrubber driers >  Ride-on floor scrubber driers
Code: 8.572.0004
A35 8500


Suitable for maintenance and deep cleaning of medium and large areas (up to 7,000 m²). More than 120-170 kg of constant pressure on the brushes. solution tank capacity 300 liters allows exceptional autonomy and productivity. Stability even when fully loaded. Innovative traction system with three independent motor wheels controlled by electronic cards. Easy access to electrical components Automatic brush plate lifting system. Automatic lifting system. Automatic squeegee squeegee lifting while reverse going. Automatic control system for brush rotation and detergent water outflow. Antifoam device. Self-levelling brushes, hour meter, solenoid valve. High-performance batteries resulting in high-working-scrubber driers efficiencyFloor. Designed to perform the hardest work and to resist even to extreme stresses with maximum comfort; the frame is made of steel with a thickness profiles varying from 5 to 12 mm, protected with a high resistance corrosion-proof paint. The unique anti foam device dramatically reduces the foam generation and prevents it from touching the suction motor, thus protecting its operation.The electronic switch floating stops suction when the tank is full.Large tank opening for fast and easy cleaning and sanification. The cleaning solution tank with an exceptional capacity of 300 liters and the high autonomy of the battery ensure to productivity at the top of the range. The wide rear opening allows for an easy and quick refilling of the cleaning solution tank. The motorwheels, designed and built by Lavor, grant optimal performance and exceptional reliability (over 30,000 hours). The innovative three-wheel drive system ensures perfect traction in every operating condition. The high power of the three motorwheels allows the machine to get over remarkable slopes.

Technical characteristics

Voltage 36 V
Scrubbing width 1220 mm
Squeegee width 1450 mm
Max working capacity 8540 m2/h
Detergent tank capacity 280 l
Recovery tank capacity stop/total 315 / 340 l.
Traction 3 Wheels Drive / 3 x 600 W
Brush motor power 3 x 1000 W
Depression / vacuum motor power 1800 mmH2O/ 600 W
RPM / Brush pressure 150 RPM/ 170 Kg
Detergent solution system 15% / 14%

Standard accessories

PPL Brush ø 406 mm-16 "

PPL Brush

?? 406 mm-16 "

Front squeegee blade L.1500 mm 4 mm 40 Th.

front squeegee Blade L.1500 mm 4 mm 40th.

Rear squeegee blade L.1580 mm 33 Th. 6 mm

rear squeegee Blade L.1580 mm 33 Th. 6 mm


Tubular battery 36V 525Ah C5

tubular shutter

Batteries 36V 525Ah C5

Battery charger 24/36V 50/60A-220-240 v 50-60

Charger 24/36V 50/60A-220-240/50-60

Polyurethane front blade L. 1270 TH. 4

polyurethane front Blade L. 1270 TH. 4

Polyurethane rear blade L.1345 TH. 6

Blade rear polyurethane

L.1345 TH. 6

Tynex Brush ø 406 mm-16 "

Tynex Brush??? 406 mm-16 "

PPL brush 0.03 ø 406 mm-16 "

PPL brush 0.03

?? 406 mm-16 "

PES brush ø 406 mm-16 "

PES brush??? 406 mm-16 "

EWU pad holder ø 406 mm-16 "

EWU pad holder?? 406 mm-16 "

Abrasive disc ø 406 mm-16 "-beige

abrasive disc?? 406 mm-16 "-beige

Abrasive disc ø 406 mm-16 "-green

abrasive disc?? 406 mm-16 "-green

Abrasive disc ø 406 mm-16 "-black

abrasive disc?? 406 mm-16 "-black
