Fasa  MONTIGO 1611 LP

Professional high pressure cleaners >  Hot water high pressure cleaners
HORECA / SANITARY / PUBLIC
Code: 8.630.0106
MONTIGO 1611 LP


Automatic Stop

Features

4 poles electrical motor (1450 RPM) with thermal protection. Three ceramic coated pistons, brass linear pump head with built-in by-pass valve. Low voltage and delayed Total Stop. Suction and delivery valves s/s. Vertical burner with high thermal efficiency steel coil. Temperature regulation gauge withsensitive stainless steel coil. Low fuel light lamp bulb and cut off. Safety valve. Built-in detergent tank for indirect suction. Auxiliary motor for burner. Hose-reel (optional).

Technical characteristics

Absorbed power 4,3 kW
Voltage 400V-50 Hz
RPM 1450 RPM
Max temperature 140 °C
Delivery rate 660 l/h
Working pressure 160 bar

Standard accessories

37000036 PISTOLA M22.png

M22-gun 3/8 with Swivel connection

M22-Gun 3/8 & nbsp; with Swivel


700 mm Lance 1/8 "F high/low press.

700 mm Lance

1/8 "F Hi/Lo press.


045 nozzle


045 Nozzle

TUBO ALTA PRESSIONE 10 M.png

H.p. hose 8 m M22-3/8 "F

H.p. Hose 8 m

M22-3/8 "F

Optional


300 bar gun 3/8 "M-1/4" F (*)

300 bar Gun 3/8 "M-1/4" F (*)

66020035 SPAZZOLA FISSA.png

Fixed brush with extension 700 mm

fixed Brush with extension 700 mm for pistol M22, max 250 bar, max. 90?

° C

spazzola 66030004.png

Professional rotary brush M22

rotating Brush professional

M22

46060053 ADATTATORE.png

Jointing pipes fitting M22-3/8 "(**)

M22-pipes joint Connector 3/8 "(**)


High-pressure hose 10 m

high-pressure hose 10 m

LANCIA SCHIUMA MAX 250 BAR.png

Indirect foam Lance

foam Launches max 250 bar. Indirect temperature foam Lance max. 90?° c. M22

gun

LANCIA SCHIUMA CON ATTACCO M22 MAX 180 BAR.png

Indirect foam Lance

Launches indirect foam with 180 bar max: max 60?° c. To mount M22 pistol.

LANCIA SCHIUMA CON ATTACCO M22.png

Foam lance

foam spear 180 bar max, max temperature 60?. Indirect foam Lance with regulator and plastic tank. To mount M22 pistol.

filtro acqua 31020011.png

Inlet water filter 3/4F-3/4 M

suction Filter 3/4F-3/4 M

Other versions of MONTIGO LP

Search Utility

APPLICATIONS & USEs

Fasa  MONTIGO 1611 LP

Horeca

Hotels, guesthouses, B & B-Resort, residences, camping sites, holiday cottages-bars, CAFè-restaurants and pizzerias-Kitchens-Catering-fast food chains and slow food

Sanitary

Hospitals and private clinics-health-medical offices and clinics-homes for the elderly and care-laboratories-dentists-Veterinary Clinics

Public

Schools and University-Kindergartens and libraries-kitchens-canteens and Gyms, stadiums, tennis courts, sports halls-churches, oratories and religious Institutions-municipalities and provinces-airports, railway stations, metro-Barracks, military bases
