Fasa MONTIGO 1611 LP

Fasa  MONTIGO 1611 LP

Professional high pressure cleaners >  Hot water high pressure cleaners
HORECA / SANITARY / PUBLIC
Code: 8.630.0106
MONTIGO 1611 LP


Automatic Stop

Features

4 poles electrical motor (1450 RPM) with thermal protection. Three ceramic coated pistons, brass linear pump head with built-in by-pass valve. Low voltage and delayed Total Stop. Suction and delivery valves s/s. Vertical burner with high thermal efficiency steel coil. Temperature regulation gauge withsensitive stainless steel coil. Low fuel light lamp bulb and cut off. Safety valve. Built-in detergent tank for indirect suction. Auxiliary motor for burner. Hose-reel (optional).

Technical characteristics

Absorbed power 4,3 kW
Voltage 400V-50 Hz
RPM 1450 RPM
Max temperature 140 °C
Delivery rate 660 l/h
Working pressure 160 bar

Standard accessories

M22-gun 3/8 with Swivel connection

M22-Gun 3/8 & nbsp; with Swivel

700 mm Lance 1/8 "F high/low press.

700 mm Lance

1/8 "F Hi/Lo press.

045 nozzle


045 Nozzle

H.p. hose 8 m M22-3/8 "F

H.p. Hose 8 m

M22-3/8 "F

Optional

300 bar gun 3/8 "M-1/4" F (*)

300 bar Gun 3/8 "M-1/4" F (*)

Fixed brush with extension 700 mm

fixed Brush with extension 700 mm for pistol M22, max 250 bar, max. 90?

° C

Professional rotary brush M22

rotating Brush professional

M22

Jointing pipes fitting M22-3/8 "(**)

M22-pipes joint Connector 3/8 "(**)

High-pressure hose 10 m

high-pressure hose 10 m

Indirect foam Lance

foam Launches max 250 bar. Indirect temperature foam Lance max. 90?° c. M22

gun

Indirect foam Lance

Launches indirect foam with 180 bar max: max 60?° c. To mount M22 pistol.

Foam lance

foam spear 180 bar max, max temperature 60?. Indirect foam Lance with regulator and plastic tank. To mount M22 pistol.

Inlet water filter 3/4F-3/4 M

suction Filter 3/4F-3/4 M

Other versions of MONTIGO LP

Search Utility

APPLICATIONS & USEs

Fasa  MONTIGO 1611 LP

Horeca

Hotels, guesthouses, B & B-Resort, residences, camping sites, holiday cottages-bars, CAFè-restaurants and pizzerias-Kitchens-Catering-fast food chains and slow food

Sanitary

Hospitals and private clinics-health-medical offices and clinics-homes for the elderly and care-laboratories-dentists-Veterinary Clinics

Public

Schools and University-Kindergartens and libraries-kitchens-canteens and Gyms, stadiums, tennis courts, sports halls-churches, oratories and religious Institutions-municipalities and provinces-airports, railway stations, metro-Barracks, military bases
